PKN-150 Portable Inner Expand Type Pipe Beveling Machine

    1. PKN series pipe beveling machine is an inner up mounted card type pipe beveling machine,

    2. using single phase AC 220V power supply double insulation treatment, manual feed.

    3. It has the advantages of small size, light weight, high power, high quality, fast speed and wide application range.

    4. One person can work in any direction.

    5. It is an ideal groove tool for field maintenance and production in power plants or other industries.


Inquire Now Next Product
Product features

PKN series pipe beveling machine is an inner up mounted card type pipe beveling machine, using single phase AC 220V power supply double insulation treatment, manual feed. It has the advantages of small size, light weight, high power, high quality, fast speed and wide application range. One person can work in any direction. It is an ideal groove tool for field maintenance and production in power plants or other industries.

Product TypePKN-76PKN-160PKN-400
Scope of Bevelling

Internal Dia:27mm

External Dia: 76mm

Internal Dia:56mm

External Dia:160mm

Internal Dia:111mm

External Dia: 402mm

Thickness of  groove122020
Distance of cutting feed303050
Power Parameter220V/50HZ220V/50HZ220V/50HZ
Motor Power130013001300
Motor BrandMetabo, GermanyMetabo, GermanyMetabo, Germany
Operation Weight kg52025
